MORE CAPACITY. MORE CAPABILITY. MORE PRODUCTIVITY.
The JMC N730 is engineered for businesses that require greater payload capacity and dependable performance for demanding transport operations. Powered by a 2.8L Turbo Intercooler CRDi diesel engine and paired with a proven 5-speed Magna Getrag transmission, the N730 delivers the strength, efficiency, and durability needed for logistics, construction, distribution, and commercial hauling. Its spacious ergonomic cabin and high-strength steel chassis provide both driver comfort and long-term reliability.
With a payload capacity of up to 3,000 kg, the N730 is built to move heavier loads while maintaining operational efficiency. Available in Single Cab and Double Cab configurations, it can be customized into Dropside, Aluminum Van, Refrigerated Van, Stake Van, or Wing Van body applications to support a wide range of business requirements. The N730 is the ideal solution for companies looking for a durable, versatile, and cost-effective commercial truck.
|
MECHANICAL FEATURES
|
SINGLE CABIN
|
DOUBLE CABIN
|
|---|---|---|
|
Engine Model
|
JX493ZLQ4H
|
|
|
Engine Type
|
4-cylinder, Turbo-Intercooler, CRDI, Diesel Engine
|
|
|
Displacement
|
2771
|
|
|
Max Torque (Nm/rpm)
|
330/1600-2200
|
|
|
Max Power [Kw(Hp)/rpm]
|
90(120)/3200
|
|
|
Emission Level
|
Euro IV
|
|
|
Fuel Tank Capacity (L)
|
100 (Aluminum)
|
64 (Aluminum)
|
|
Transmission
|
5-Speed Manual Magna (Getrag)
|
|
|
DIMENSION & WEIGHT
|
|
|
|---|---|---|
|
Gross Vehicle Weight (kg)
|
5495
|
|
|
Payload (kg)
|
3000
|
|
|
Overall Dimension (LxWxH)
|
5990 x 2080 x 2450
|
5490 x 2080 x 2450
|
|
Cargo Length (ft)
|
14
|
9
|
|
Wheelbase (mm)
|
3360
|
2850
|
|
OTHER FEATURES
|
|
|
|---|---|---|
|
Tilting Cabin
|
Standard
|
N / A
|
|
Seat Capacity
|
3
|
5
|
|
Air Conditioning
|
Standard
|
|
|
Windows
|
Standard - Powered
|
|
|
Central Locking
|
Standard
|
|
|
Audio System
|
Radio, USB and Bluetooth
|
|
|
Brakes [Service / Parking]
|
Hydraulic with ABS / Mechanical
|
|
|
Suspension [Front & Rear]
|
Leaf Spring and Shock Absorber
|
|
|
Alternator
|
12V 110A
|
|
|
Tire Size
|
7.00R16LT 16PR
|
|
|
Number of Tires
|
6 + 1 spare
|
|
|
Number of Studs
|
6
|
|
|
