BUILT STRONGER. CARRY MORE. GO FURTHER.
The JMC N710 is built to handle demanding commercial operations with power, efficiency, and reliability. Equipped with a 2.8L Turbo Intercooler CRDi diesel engine, high-strength steel chassis, and 5-speed Magna Getrag transmission, it delivers the performance businesses need for logistics, distribution, construction, and cargo transport. Its spacious and ergonomic cabin ensures greater comfort for drivers, even during long working hours.
Available in Single Cab and Double Cab variants, the N710 supports a payload capacity of up to 2,500 kg and can be configured as a Dropside, Aluminum Van, Refrigerated Van, or Stake Van. Combining durability, versatility, and low operating costs, the N710 is a dependable transport solution designed to keep your business moving forward.
|
MECHANICAL FEATURES
|
SINGLE CAB
|
DOUBLE CAB
|
|---|---|---|
|
Engine Model
|
JX493ZLQ4H
|
|
|
Engine Type
|
4-cylinder, Turbo-Intercooler, CRDI, Diesel engine
|
|
|
Displacement (cc)
|
2771
|
|
|
Max Torque (Nm/rpm)
|
330@1600-2200
|
|
|
Max Power [Kw(Hp)/rpm]
|
90(120)/3200
|
|
|
Emission Level
|
EURO IV
|
|
|
Fuel Tank Capacity (L)
|
64 (Aluminum)
|
|
|
Transmission
|
5-Speed Manual Magna (Getrag)
|
|
|
DIMENSION & WEIGHT
|
|
|
|---|---|---|
|
Gross Vehicle Weight (kg)
|
4495
|
|
|
Payload
|
2500
|
|
|
Overall Dimension (LxWxH) (mm)
|
5490 x 2060 x 2450
|
|
|
Cargo Length (ft)
|
12
|
9
|
|
Wheel Base (mm)
|
2850
|
|
|
OTHER FEATURES
|
|
|
|---|---|---|
|
Tilting Cabin
|
Standard
|
N / A
|
|
Seat Capacity
|
3
|
5
|
|
Air Conditioning
|
Standard
|
|
|
Windows
|
Standard - Powered
|
|
|
Central Locking
|
Standard
|
|
|
Audio System
|
Radio, USB and Bluetooth
|
|
|
Brakes [Service / Parking]
|
Hydraulic with ABS / Mechanical
|
|
|
Suspension [Front & Rear]
|
Leaf Spring and Shock Absorber
|
|
|
Alternator
|
12V 110A
|
|
|
Tire Size
|
7.00R16LT 16PR
|
|
|
Number of Tires
|
4 + 1 spare
|
|
|
Number of Studs
|
6
|
|
